Product Summary

The 3266W-1-502LF is a type of square trimming potentiometer, which is characterized by tape and reel packaging, Standoffs allow thorough PC board washing, RoHS compliant, etc. Its standard resistance ranges from 10 meg ohm to 1 megohm.What is more, its absolute minimum resistance is 1 % or 2 ohms max(whichever is greater).

Parametrics

Electric characteristis:(1)standard resistance range: 10 meg ohm to 1 megohm;(2)resistance tolerance is±10 % std;(3)absolute minimum resistance: 1 % or 2 ohms max(whichever is greater).(4)contact resistance variation: 3.0 % or 3 ohms max(whichever is greater).(5)adjustab ility:Voltage: ±0.02 %; resistance: ±0.05 %, resolutionis Infinite insulation resistance: 500 vdc and 1,000 mego hms min; (6)dielectric strength:sea level: 600 vac; 80,000 feet: 250 vac; effective travel: 12 turns nom.

Features

Features:(1)multiturn / cermet / industrial /sealed;(2)standoffs allow thorough PC board washing;(3)tape and reel packaging available;(4)patent #4427966 drive mechanism;(5) roHS compliant* version available.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
3266W-1-502LF
3266W-1-502LF
Bourns
Trimmer Resistors - Through Hole 1/4" 5Kohms 10% SQ W/Standoff Sealed
Data Sheet
0-1: $2.71
1-10: $2.42
10-50: $2.11
50-100: $1.73
